5 KVA Petrol Genset

5 kVA TECHINCAL SPECIFICATION

General Specifications

Feature	2.8 kW (Inverter)	5 kW
Rated Output (at 230V/50Hz)	2.8 kW	5 kW
Max Ratings (kW/kVA)	2.8 kW	5 kW
Generator Model	KBI-P-2.8S	KBI-P-5.0S
Voltage (V)	230	230
Sound Level (Lw/dB(A))	85	85
Fuel Consumption (Ltrs/Hr):
- 100% Load	1.82	2.63
- 75% Load	1.23	2.37
- 50% Load	1.00	1.88
Fuel Tank Capacity (Ltrs)	12.5	12.5
Dimensions (L x W x H, mm)	820 x 480 x 630	1040 x 650 x 685
Weight (kg)	150	170

---

Engine Specifications

Feature	CCP198	CCP389
Engine Model	CCP198	CCP389
Rated Output (kW)	3.67	6.5
Horsepower (HP)	5	8.8
Cubic Capacity (cc)	196	389
Lube Oil Change Period	First 20 hrs, then every 100 hrs	First 20 hrs, then every 100 hrs
Lube Oil Sump Capacity (Ltrs)	0.9	1.1
Starting System	Electric/Recoil	Electric/Recoil
Low Oil Level Alert (Trip)	Yes	Yes
Overload Warning	Yes	Yes
Battery Charging	Yes	Yes
Eco Throttle	Electronic	Electronic

---

Inverter Specifications

Feature	2.8 kW	5 kW
Rated Output (at 230V/50Hz)	2.8 kW	5 kW
Max Output (kW)	3	-
Total Harmonic Distortion (THD)	5%	5%
Display Parameters	Digital Multi-Function Meter: Voltage, Frequency, Hours	Digital Multi-Function Meter: Voltage, Frequency, Hours
Fuel Gauge	Yes	Yes
AC Output Sockets	Yes	Yes
AC Circuit Breaker	Yes	Yes
